SpecsConnectivity

• Wheel SensorCannondale Wheel Sensor

Drivetrain

• Bottom Bracket Cartridge, sealed
• Chain KMC E9T, 9-speed
• Crank Prowheel, 38T
• Rear Cogs Sunrace, 11-36, 9-speed
• Rear Derailleur Shimano Alivio
• Shifters Shimano Acera, 9-speed

Frameset

• Fork SmartForm C3 Alloy blades, 1-1/8″ steerer, OutFront offset, flat mount disc, mid-blade rack/fender mounts
• Frame SmartForm C3 Alloy, low standover Ride-Easy geometry, internal downtube battery, hidden cable routing, Urban Armor frame bumpers, flat mount disc, rack/fender mounts, kickstand mount
• Low standover Ride-Easy geometry
  • Internal downtube battery
  • Hidden cable routing
  • Urban Armor frame bumpers
  • Flat mount disc
  • Rack/fender mounts
  • Kickstand mount
• Headset FSA, Alloy, 1-1/8″ Ahead, semi-integrated

Wheels

• Front Hub Sealed Alloy Disc, 12×100
• Front Tire Maxxis DTR-1, 650b x 47c
• Rear Hub MAHLE ebikemotion X35 250W
• Rear Tire Maxxis DTR-1, 650b x 47c
• Rims Cannondale Disc, double wall w/eyelet, 32h
• Spokes Stainless Steel, 14g
• Tire Size 47
• Tires Maxxis DTR-1, 650b x 47c
• Wheel Size 27.5

Brakes

• Brake Levers Tektro hydraulic disc
• Brakes Tektro HD-R280 hydraulic disc, 160/140mm rotors

Components

• Grips Cannondale Comfort
• Handlebar Cannondale Cruise Control riser, 6061 Alloy, 31.8mm, 15° back, 740mm
• Saddle Cannondale Treadwell, 170mm, steel rails
• Seatpost Promax Suspension Seatpost, 31.6, 40mm
• Stem Cannondale 3 with Intellimount with high direct light mount, Alloy, 31.8mm clamp

E-System

• E-System Drive Unit



  Mahle ebikemotion X35 250W
• E-System Battery



  Mahle ebikemotion X35 250Wh
• E-System Charger



  Mahle ebikemotion X35
• E-System Display



  Mahle ebikemotion iWoc ONE integrated controller, iWoc Trio, smartphone app with Intellimount stem

Extra

• Extra 1



  Herrmans H-Black MR8 front light / Herrmans H-trace rear light, fenders, front rack (10kg max capacity), kickstand, Cannondale Wheel Sensor
